Geshelli Labs launches TORC modular DAC platform
The desktop converter is built around replaceable DAC boards, swappable output-stage parts and optional I/O expansion. It gives buyers a configurable route through Geshelli’s DAC range without making every change a full-box replacement.
Georg S. Kuklick
•
Geshelli Labs has launched the TORC DAC, a desktop digital-to-analogue converter built as a modular platform rather than a fixed-spec component. The launch matters for buyers who want to configure or later alter a DAC’s conversion stage, output stage and input/output hardware without moving to a different chassis.
The TORC is based on replaceable DAC boards and an interchangeable I/O board. Its design also allows hardware-level tuning through four socketed mono/single op-amp positions, while relay-switched digital inputs are used for source selection.
The platform sits in Geshelli’s established direct-sale, configurable product model. The submitted AXPONA 2026 coverage also places the TORC in the company’s show system, while Geshelli’s own TORC information and FAQ pages define the supported module families and note that DSD support depends on the installed DAC module.
Key specifications
DAC platform | Replaceable DAC boards and interchangeable I/O board |
|---|---|
DAC module options | AD1862, AK4499EXEQDM, AK4499EXEQ, AK4493S, ES9026PRO, ES9039SPRO, ES9039Q2M and PCM1794 |
Op-amps | Four socketed mono/single op-amp ports |
Standard inputs | Two coaxial and two Toslink SPDIF inputs, PCM up to 24-bit/192 kHz |
Optional USB | Amanero USB 2.0 High Speed, plug-and-play for Linux, macOS and Windows 11; PCM up to 32-bit/768 kHz and DSD64–DSD512 with a compatible DAC module |
Standard outputs | RCA unbalanced left/right pair and XLR balanced left/right pair |
Optional expansion | GIO expansion with AES input, additional SPDIF coax/Toslink, additional RCA output and 4.4 mm balanced output |
Power supply | Internal 20 W AC/DC supply with IEC cable input, isolated digital rails, isolated analog positive/negative 11 V rails and isolated supply for the optional I/O expansion card |
The TORC DAC is listed at $699.99. Geshelli’s product title carries an 8–10 week shipping estimate, and the product page showed an out-of-stock status when checked during research.
