Momentum C2 / C2Z Preamplifier
Dan D’Agostino launches Momentum C2/C2Z preamplifier
The new Momentum platform separates the standard C2 from the C2Z variant for systems using Momentum Z power amplifiers. An optional Digital Streaming Module brings network and digital-source integration to the analogue preamplifier design.
Georg S. Kuklick
•
Dan D’Agostino Master Audio Systems has listed the Momentum C2 / C2Z Preamplifier, a two-chassis preamplifier platform in its Momentum range. The product launch covers the standard Momentum C2 and the Momentum C2Z, with the C2Z configured for use with Momentum Z power amplifiers.
The Momentum C2 uses a new architecture built around a complementary four-circuit topology inspired by the company’s Relentless Preamplifier. The C2 and C2Z share the same core design, features and operation, with the stated difference being the C2Z’s FET-based output stage, which is intended to deliver greater current to the Z input stage used in Momentum Z amplifiers.
The preamplifier uses a separate power-supply chassis with custom toroidal transformers for analogue and digital circuitry. An optional Digital Streaming Module can be fitted for digital and network sources, while the main unit also includes tone-control circuitry, a front-panel headphone output with independent amplifier circuitry, and a bidirectional remote control.
Key specifications
Architecture | Complementary four-circuit topology |
|---|---|
Power supply | Separate chassis with custom toroidal transformers for analogue and digital circuitry |
Frequency response | 0.1 Hz to 1 MHz, -1 dB; 20 Hz to 20 kHz, ±0 dB |
Gain | +10 dB (C2); 11.5 dB (C2Z) |
Input impedance | 1 MΩ |
Output impedance | 0.05 Ω (C2); 0.01 Ω (C2Z) |
Distortion | <0.002% full output (C2); <0.00066% full output (C2Z) |
Analog inputs | 3 pairs balanced XLR stereo; 1 pair unbalanced RCA stereo |
Digital inputs | SPDIF coaxial, optical, USB-B, RJ45 Ethernet and Wi-Fi with optional DSM |
Outputs | 2 pairs balanced XLR stereo; ¼-inch headphone |
Digital support | PCM up to 32-bit/384 kHz; DSD up to DSD256/11.2 MHz with optional DSM |
Dimensions | 17.0 x 8.9 x 15.2 in / 43.2 x 22.6 x 38.6 cm |
Weight | 73 lb / 33.1 kg |
Finish | Silver or Black |
Final retail pricing and availability for the Momentum C2Z were still to be confirmed at publication time. Secondary coverage from eCoustics and HiFi Pig also listed price and availability as not yet confirmed.
