Matrix Audio introduces SU-1 USB isolator for hi-fi systems
The Matrix Audio SU-1 provides galvanic isolation for USB-connected hi-fi and AV equipment. Its design combines three USB inputs and two outputs with a multichannel, linearly regulated power supply.
Georg S. Kuklick
•
Matrix Audio has introduced the SU-1 USB isolator for hi-fi and AV applications. The device provides galvanic isolation between a USB host and connected equipment and has a recommended retail price of €899. It is available through specialist retailers, with distribution handled by DREI H.
The SU-1 has three USB inputs and two USB outputs, with support for Type-A, Type-B and Type-C connections. It supports a combined input-and-output USB cable length of up to 8 metres. That figure covers the total cable length on both sides of the isolator.
Power comes from a multichannel, linearly regulated supply incorporating a fully encapsulated toroidal transformer. The unit's power output is rated at 5 V/1 A. Its USB circuitry also incorporates optimised transmission impedance.
The enclosure is made from fully CNC-machined aluminium alloy, with an operating-status indicator on the front panel. The SU-1 measures 120 mm wide, 205 mm deep and 44 mm high, and weighs 1.58 kg.
Key specifications
USB isolation | Galvanic isolation between host and connected device |
|---|---|
Power supply | Multichannel linear regulation with a fully encapsulated toroidal transformer |
Power output rating | 5 V / 1 A |
USB inputs | 3 |
USB outputs | 2 |
Supported USB connector types | Type-A, Type-B and Type-C |
Maximum combined USB cable length | 8 m across input and output cables |
Status indication | Front-panel operating-status indicator |
Enclosure | Fully CNC-machined aluminium alloy |
Dimensions | 120 × 205 × 44 mm (W × D × H) |
Weight | 1.58 kg |
