Ascendo introduces DSP4-6602 cinema DSP amplifier
The four-channel amplifier is aimed at residential cinema systems that need high-current low-frequency drive with installation control. Ascendo is positioning it for integrators working with larger subwoofer and infrasonic speaker layouts.
Georg S. Kuklick
•
Ascendo Immersive Audio has introduced the DSP4-6602, a four-channel DSP amplifier for demanding residential cinema installations. The amplifier is intended for low-frequency duty in systems using large Ascendo subwoofer and infrasonic speaker arrays.
The German company is targeting a familiar installation problem: delivering high output in rooms where amplifier noise, standby behaviour, trigger logic and system management still matter. The DSP4-6602 combines high-current amplification with onboard processing and control functions intended for rack-based cinema systems.
Integration features include selectable 12V trigger input logic, trigger output, configurable auto-standby and Ethernet-based multi-amplifier control or management. audioXpress also reports that Dante network audio functionality is available on Dante-enabled DSP4-6602 models.
Key specifications
Amplification | Four-channel DSP amplifier; 6600W RMS capability |
|---|---|
Rated output | 4 x 650W into 8 ohms; 4 x 1150W into 4 ohms; 4 x 1650W into 2 ohms |
Bridged output | 2 x 2200W into 8 ohms; 2 x 3330W into 4 ohms |
Load support | Stable at 2 ohms; bridgeable into 4-ohm loads |
Frequency response | ±1.0 dB from 5 Hz to 20 kHz at 10 percent rated power into 8 ohms |
DSP | 4x4 routing and mixing; input and output parametric EQ; high- and low-pass filters; FIR filters; delay, volume, mute, polarity and limiter functions |
Control | 12V trigger input logic, trigger output, auto-standby and Ethernet-based multi-amplifier management |
Network audio | Dante functionality on Dante-enabled models |
The DSP4-6602 is now listed on Ascendo’s product site. Pricing and shipping timing are not included in the verified product information.
